GFS Aerospace Spray Booth Filters
$150.00 – $710.00Price range: $150.00 through $710.00
Aerospace spray booth exhaust filters are M319 compliant for 2 and 3 stage systems. Test reports available.
Description
Aerospace spray booth filters are available from AJ Dralle, GFS, and AFC.
The XFP-6000 industrial filtration system delivers superior 3-stage performance, exceeding NESHAP Method 319 standards. Engineered for challenging environments like aerospace chromate collection or spray-to-waste powder coating and dust collection systems, the precision-engineered panel and bag filters are built to retain hazardous particulates, endure extreme temperature fluctuations, and withstand high-velocity airflows without compromising filtration efficiency or structural integrity.
CPA Media:
a multi-layered, graduated density, prefilter. The air-entry side is constructed of lofted denier fiber. To densify, the air-leaving side is comprised of heavily needled media and is ink jet printed for installation ease.
$155.00Add to cart
$385.00Add to cart
$459.00Add to cart
$519.00Add to cart
$479.00Add to cart
$559.00Add to cart
$537.00Add to cart
$630.00Add to cart
$710.00Add to cart
$669.00Add to cart
ME/PT panel filter:
The ME/PT panel is constructed of 2 layers of tackified polyester media, sealed together around a wire support such that the tackified layers of each media touch in the center. The air entry layer is constructed of a multi-layered, multi-density polyester with a heavy, nonmigrating tackifier on the air-leaving side. The air leaving media is a heavily needled polyester, densified to ¼” thick and tackified on the air entry side. The air-leaving side is inkjet printed for installation.
$359.00Add to cart
$429.00Add to cart
$566.00Add to cart
CG100 Bag Filter:
For booths with 2 holding frames, the CG100 bag filter is recommended. The CG100 2 pocket bag is made of two layers of polyester media. The first layer is made of CPA media as defined in the “First Stage.” The second layer is an 8.5 ounce per square yard polyester, densified to 0.08 or 3/32 inches thick. The air leaving side is singed. The media are sewn together on the perimeter to form two pockets which are 15” deep. The bag pockets are sewn together onto a nine-gauge galvanized metal frame with a center cross-wire to support the pockets.
XFP-6000 bag filter:
The XFP-6000 6 Pocket Bag Filter is constructed using 2 plies of electrostatic medias. The first and second plies are a composite of melt blown and spun bound polyester fibers. The pockets are sewn together on the perimeter and seams forming three air channels in each pocket. A “J” channel is inserted into each finished pocket and individually placed into a header. The pockets are stapled and notched together and to the header to insure filter integrity. The galvanized header has a ¼” foam gasket on the air leaving side to prevent any paint bypass around the filter assembly.
$150.00Add to cart
$160.00Add to cart
*Note: 20x25x12″ filters are a low inventory/non-stock item and may require up to 60 days lead.
Ships manufacturer direct in 3-5 business days.
XFP-6000 2ox25x12″, 6-pocket bag filter is a non-stock item. Lead time could be up to 60 days, depending on the production schedule. Contact us to get the current lead time.
